Tension tester UT15C
DESCRIPTION
12V AC / DC voltage tester up to 690V, continuity detector with acoustic warning and LED, positive and negative polarity detector. 50HZ-60Hz phases rotation test. Voting indicator on the screen as in sequence of LEDs (7 levels). According to the EN61010-1 standards, at 61010-2-30, EN 61243-3, EN 61326-1. Double safety insulation according to IEC536 Class 11. Safety insulation Cat IV 600V.
DESCARGAR FICHA TÉCNICA
520000160.pdf
Mi Descargar ficha técnica del producto 520000160
* Taxes and transport excluded
| AC/DC voltage levels by Led | 12V: Between 0-12V the LED lights // 24V: Between 19V 2V the LED lights // 50V: Between 48V 6V the LED lights // 120V: Between 110V 20V the LED lights // 230V: Between 200V 20V the LED lights // 400V: Between 340V 30V the LED lights // 690V: Enter |
|---|---|
| Range continuity test | 0-100k? |
| Phase rotation test | 500Hz - 60Hz |
| Battery | 1,5V (AAA) x 2 V. |
| Dimensión aparato | 275x51x30 mm. |
| Weight in grams | 210 gr. |
