MIG / MAG INVERTER EASY JOB 525E LAB 230V / F1 with ACC.
DESCRIPCIÓN
EasyJob 525E LAB is the perfect synergic multiprocess multiprocess solder for any
Garage and well-equipped workshop.
EasyJob 525E Lab supplies 250 A in continuous current (CC). The supply voltage It is single-phase 230 volts. It offers 4 welding processes always by hand:
MIG / MAG, FLUX, MMA and TIG LIFT. In MiR / MAG and Flux modes, easyJob 525E Lab is Perfect for welding steel, stainless steel, aluminum and to use wires Strong welding
DESCARGAR FICHA TÉCNICA
383247100.pdf
Mi Descargar ficha técnica del producto 383247100
* Impuestos y transportes excluidos
| Feed | 230v / f1 |
|---|---|
| Power consumed: 60% / max. | 3,3 / 6,3 Kw |
| Fuse | 25 Amp. |
| Compatible generator | 9 KW/KVA. |
| Welding regulation | 10 - 250 MIG-TIG / 10-200 MMA Amp. |
| EN60974-1 Service (40oC) | MIG-TIG 220A-20% / MMA 180A-25% MIG-TIG 120A-60% / MMA 120A-60% Amp. |
| Vacuum tension | 96 Volt. |
| Diameter thread steel | 0,6 - 0,8 - 0,9 - 1,0 - 1,2 mm. |
| Diameter thread stainless steel. | 0,8 - 1,0 mm. |
| Diameter thread aluminum | 0,8 - 1,0 - 1,2 mm. |
| Diameter tubular thread | 0,8 - 0,9 - 1,0 - 1,2 mm. |
| Coil thread | 200 - 300 mm. |
| Usable electrodes | MMA 1,6-4,0 / TIG 1,0-4,0 Ø mm. |
| Cinch connector | 50 mm. |
| Euro torch | IF |
| Net / crude weight | 30 / 35 Kg. |
| Dimension | 777 X 407 X 792 mm. |
| Dimensions packaging | 800 X 300 X 650 mm. |
