Lathe FTX-914X300-TO DCR 400V / F3 with Bencada. + DR O + TCRE
DESCRIPTION
Lathe to work metals, of professional use, of robust design with laminated and rectified prismatic guides, with rear protector, refrigeration pump, foot brake, automatic gearboxed gearbox. Spindle with conical roller bearings, adjustable wedge-shaped cars. Stopper microswitch by opening pulley cap or plate protector. Clipping plate protector and turret. Emergency stop Automatic longitudinal and transverse movement. Dial Thread Indicator. Race stopper longitudinal carriage stop. Machines manufactured according to EC standards.
DESCARGAR FICHA TÉCNICA
441080000.pdf
Mi Descargar ficha técnica del producto 441080000
* Taxes and transport excluded
| Coordinate viewer X/Y | IF |
|---|---|
| Alimentación | 230V/F1 |
| Potencia | 1.1 - 1.5 Kw-Hp |
| Change speeds | ENGRATMENTS |
| Diameter on bench | 300 mm. |
| Diameter on neckline | 430 mm. |
| Diameter on cart | 190 mm. |
| Banking width | 180 mm. |
| Inner diameter spindle | 38 mm. |
| Distance between points | 914 mm. |
| Point | MT5 |
| Cone contrapoint | MT3 |
| Diameter counterpoint | 32 mm. |
| Tour counterpoint | 90 mm. |
| Número de velocidades | 18 |
| Spindle speed range | 65 - 1810 r.p.m. |
| Longitudinal forward range | 0.079 - 1,291 mm/rev. |
| Cross-sectional forward range | 0.017 - 0.276 mm/rev. |
| A. Rapid longitudinal intermediate car | - m/min. |
| A. Cross-sectional carriage | - m/min. |
| Range metric steps | 36 TIPOS / 0.4 - 7 mm. |
| Rank inches | 36 TIPOS / 4 - 60 tpi |
| Range diametric steps | - d.p. |
| Range modular steps | - m.p. |
| Peso Neto/Bruto | 540 Kg. |
| Dimensiones | 1850X750X1460 mm. |
